18
DATA1 to DATA3 ports
These ports connect to the equipment shown in the table below.
DATA1 (7P)
DATA2 (6P)
DATA3 (7P)
GPS receiver GP-310B/320B,
NMEA equipment
Heading sensor
(ex. SC-60/120)
RS-232C OUT, NMEA 0183 IN,
External buzzer OUT
Note:
No sensor can be directly connected to the DATA3 port.
This equipment can receive the following NMEA 0183 format sentences from other
equipment.
•
Own ship’s position:
GGA>RMC>RMA>GLL
•
Ship’s speed:
RMC>RMA>VTG>VHW
•
Destination waypoint:
RMB
•
Heading (True):
HDT>HDG>HDM
•
Course: RMC>RMA>VTG
•
Depth: DPT>DBT
•
Temperature:
MTW
•
Time:
ZDA
•
Other ship’s information:
TTM
•
Insight satellite information:
GSV
•
Wind speed and angle:
MWV>VWT>VWR
NETWORK port
This port connects other NavNet equipment, with the optional NavNet cable. Available
equipment are shown in the table below.
Radar Plotter
Network
sounder
Other
MODEL1724C/1734C GD-1720C
ETR-6/10
ETR-30N
HUB (used when more
than two NavNet units
are connected.)
