5. Using On-Screen Display
90
Input
The Input tab displays various source and frequency values at a glance.
The following table lists all items with a description.
I
TEM
D
ESCRIPTION
Input name
Displays the Input Terminal that is presently being used
(see Default input select on page
86 ).
Signal
Displays the Source name of the signal presently being used
(see Option on page
83 ).
H-sync. freq. Displays Horizontal frequency in KHz.
V-sync. freq. Displays Vertical frequency in Hz.
Video type Displays Video type.
Sync type Displays Sync type.
Sync polarity Displays Sync polarity.
Scan type Displays Scan type.
