5. Using On-Screen Display
62
Image options menu
The Image Options menu is used to configure image options such as screen positioning and aspect ratio. Access the im-
age options menu in the Adjust menu.
The following table lists all functions with a description and the default setting.
I TEM D ESCRIPTION
Screen Select Screen using ◄or► from the list (see page 63 ).
Overscan Set the Overscan value using ◄or► (see page 63 ).
PC adj.
Adjust the position values using the slides.
Horizontal: Adjusts the image location horizontally using ◄or►.
Vertical:
Adjusts the image location vertically using ◄or►.
Total dots: Fine tune a computer image or remove any vertical banding that might appear.
Fine sync: Adjust the clock phase or reduce video noise, dot or cross talk.
Note:
Only use the Phase settings after the total dots settings have been modified.
WXGA Mode Select WXGA Mode (see page 63 ).
