The high-current fuses are coded as follows:
Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
1
60A**
PJB
2
30A**
BSM
3
20A**
GCC pusher fan (export only)
4
30A**
Rear defrost
5
40A**
Anti-lock Brake System (ABS)
pump
6
60A**
Delayed accessory circuit breaker
7
20A**
Power point #2
8
—
Not used
9
20A**
Power point #1
10
30A**
ABS module (valves)
11
40A**
PTEC
12
50A**
Ignition relay/Starter relay
13
40A**
Trailer tow battery, Trailer tow
turn signals
14
10A*
Daytime Running Lamps (DRL)
(Canada)/Foglamps (export only)
15
15A*
Memory (KAPWR)
16
15A*
Headlamp switch
17
20A*
4x4 (v-batt 2)
18
20A*
4x4 (v-batt 1)
19
20A**
High beam relay
20
30A**
Electric brake
21
30A**
Front wiper motor
22
20A**
Autolamp; Low beam
23
30A**
Ignition switch
24
20A*
Rear fog lamps (Export only)
25
–
Not used
26
15A*
Fuel pump
27
20A*
Trailer tow lamps
