Page 231

Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
22
10A
ABS, IVD Controller
23
15A
Brake pedal position switch,
Driver brake applied relay,
Redundant cruise deactivate
switch
24
15A
Cigar lighter, OBD II
25
5A
Mode-Temperature actuator for
auxiliary climate control, Trailer
tow battery charge coil
26
7.5A
Park aid, Brake shift interlock,
Approach lamp relay coil, IVD
switch
27
7.5A
Electrochromatic mirror, Digital
transmission range sensor -
backup lamps
28
5A
Radio (Start)/DVD (Start)
29
10A
Digital transmission range sensor,
PWR feed to fuse #28 (Start feed)
30
5A
Daytime Running Lamps (DRL),
Remote solenoid, DEATC climate
controller
Roadside emergencies
231
