The fuses are coded as follows:
Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
1 30A Memory seat module
2 20A Heated seats, Moonroof
3 20A Radio, Amplifier, Power antenna,
DVD
4 5A Front wiper module
5 15A Flasher relay (Turn, hazards)
6 10A Right horn
7 15A Heated mirrors
8 – Not used (spare)
9 – Not used (spare)
10 10A Heated backlight relay coil,
Heated seat module, Temp blend
actuator, A/C clutch contact
11 — Not used (spare)
12 5A Foglamp switch, 4x4 module
13 5A Overdrive cancel switch, Flex fuel
sender
14 5A PATS module
15 5A Rear wiper module, Cluster, TPMS
16 5A Power mirror, Manual climate
control, TPMS
17 15A Delayed acc. coil, Battery saver,
Interior lamps (front and rear),
Glove compartment lamp
18 10A Left horn
19 10A RCM, PAD indicator
20 5A PATS, Driver seat switch, Memory
switch, Driver seat module, BSM,
Sunload sensor
21 5A Instrument cluster, Compass,
Flasher coil
Roadside emergencies
230
