Colour monitor 4312 FA
18 - English S26361-K841-V150-1-5E19
Technical data
Dimensions and weight (LCD monitor)
Visible diagonals: 43 cm
Dot pitch: 0,264 mm
Screen size: 338 ñ 3 mm x 270 ñ 3 mm
Maximal resolution: 1280 x 1024 pixels
Dimensions (W x H x D): Monitor
incl. Monitor base:
Box:
414 mm x 457 mm x 206,9 mm
507 mm x 270 mm x 532 mm
Weight: Monitor
incl. Monitor base:
Box:
6 kg
8,6 kg
Accessories: Power cable (1.8 m)
D-SUB data cable (1.8 m)
Power adapter
Storable display modes: 20 (10 of which are preset)
Power adapter
Input data
Rated mains voltage:
Frequency:
100 V - 240 V ( ñ 10 %)
50 Hz - 60 Hz ( ñ 5 %)
Output data
Rated voltage:
Output current:
14,0 V ( ñ 5 %)
≤
3 A
Electrical data
Video: analogue, positive, 0.7 Vpp, 75 Ω
Synchronisation: Separate Sync. TTL, positive or negative
Horizontal frequency: 31 kHz .... 80 kHz (multi-scanning)
Refresh rate: 56 Hz .... 75 Hz
Maximum pixel rate: 135 MHz
Power supply: 14,0 V ( ñ 5 %)
Total power consumption (incl.
power adapter): 42 W (maximum), 36 W (nominal)
< 5 W in the energy-saving mode (standby mode, suspend
mode and OFF mode)
Environmental conditions
Environment class 3K2, IEC 721
Rated range of operation:
Humidity: 15 °C .... 35 °C
20 % .... 85 %
Limit range of operation:
Humidity: 5 °C .... 35 °C
20 % .... 85 %
Condensation must be avoided.
