Page 66

6. MAINTENANCE & TROUBLESHOOTING
6-6
SYSTEM DATA
You can confirm the current equipment and drive system status.
1. Press the [TURN/MENU] key twice to show the menu.
2. Rotate the course control knob to select “SYSTEM DATA”.
3. Press the course control knob to show the system data screen.
INPUT VOLTAGE:
24.4 V
CONTROLLER ID:
1
DRIVE TYPE:
SOLENOID
BYPASS/CLUTCH:
NON
FET TEMP.:
24.6 F
MOTOR DRIVE CUR.:
0.0 A
BYPASS/CLUTCH CUR.:
0.0 A
SYSTEM DATA
ID: 1
System data screen
6.4 Clearing
Memories
Memories can be cleared to restore the Navpilot-511/520/611 to default settings.
For details, see the installation manual.
