C141-E134-01EN 2 - 2
2.1.2 Function specifications
Table 2.1 shows the function specifications of the IDD.
Table 2.1 Function specifications
Specification
Item
MAM3367 series MAM3184 series
Formatted capacity/device (*1) 36.74 GB 18.37 GB
Number of disks 4 2
Number of heads 8 4
Number of cylinders (*2) 18,754 18,786
Formatted capacity/track (B) 200, 704-265, 216
Number of rotations min
-1
(rpm) 15,000
Average latency time 2.00 msec
Track to Track
0.4 ms/0.6 ms
Average
3.5 ms/4.0 ms
Seek time (*3)
(Read/Write)
Full stroke
8.0 ms/9.0 ms
Start/stop time
(*4) Start time
Stop time 30 s typ. (60 s max.)
30 s typ.
Recording mode 32/34 MEEPRML
External
dimensions
Height:
Width:
Depth:
25.4 mm
101.6 mm
146.0 mm
Weight (max) 0.8 kg
Power consumption (*5) 11.5 W 9.5 W
Fast 5 SCSI Cable length: 6 m max
Fast 10 SCSI Cable length: 3 m max Single-
Ended
Fast 20 SCSI
Cable length: 3 m max (*6)
Cable length: 1.5 m max (*7)
Inter-
face
LVD
Cable length: 25 m max (*8)
Cable length: 12 m max (*9)
Disk drive
68.6 to 88.0 MB/s Data
transfer
rate (*10)
SCSI
Synchronous
mode
160 MB/s max.
Logical data block length (*11) 512 to 528 byte (Fixed length)
SCSI command specification
ANSI X3.131-1994 conformity
SPC-2 (T10/1236-D Rev 19), SBC (ANSI NCITS.306-1998), SAM
(ANSI
×
3.270-1996), SPI-3 (ANSI NCITS. 336-2000)
Data buffer 8 MB FIFO ring buffer
Acostic noise (Ready) 3.9 bels
