B - 2 C141-E134-01EN
B.1 Setting Terminals (MP model)
Table B.1 Setting terminal: CN2 (MP model)
Setting item Pins Setting contents
9 - 10 7 - 8 5 - 6 3 - 4 1 - 2
SCSI ID (Open) Open Open Open SCSI ID #0 (Common to 8-bit and 16-bit SCSI)
(Open) Open Open Short SCSI ID #1 (Common to 8-bit and 16-bit SCSI)
(Open) Open Short Open SCSI ID #2 (Common to 8-bit and 16-bit SCSI)
(Open) Open Short Short SCSI ID #3 (Common to 8-bit and 16-bit SCSI)
(Open) Short Open Open SCSI ID #4 (Common to 8-bit and 16-bit SCSI)
(Open) Short Open Short SCSI ID #5 (Common to 8-bit and 16-bit SCSI)
(Open) Short Short Open SCSI ID #6 (Common to 8-bit and 16-bit SCSI)
(Open) Short Short Short SCSI ID #7 (Common to 8-bit and 16-bit SCSI)
Short Open Open Open SCSI ID #8 (16-bit SCSI only)
Short Open Open Short SCSI ID #9 (16-bit SCSI only)
Short Open Short Open SCSI ID #10 (16-bit SCSI only)
Short Open Short Short SCSI ID #11 (16-bit SCSI only)
Short Short Open Open SCSI ID #12 (16-bit SCSI only)
Short Short Open Short SCSI ID #13 (16-bit SCSI only)
Short Short Short Open SCSI ID #14 (16-bit SCSI only)
Short Short Short Short SCSI ID #15 (16-bit SCSI only) (*)
Write protect Open Write operation is enabled. (*)
Short Write operation is disabled.
Setting item Pins Setting contents
11 - 12 13 - 14 15 - 16 23 - 24
Motor start mode Open Started by the START/STOP command
Short Started by turning the power supply on (*)
Force Narrow Open Width of 16 bit bus (*)
Short Width of 8 bit bus
Force Single Ended Open Follows DIFFSNS signal level on SCSI bus (*)
Short Single-Ended mode
Terminating power supply Open Does not supply terminating resistor power to SCSI BUS
Short Supply terminating resistor power to SCSI BUS (*)
* Default
Note:
See the description of Section 5.3 for details of the setting requirements and notes.
