FUJITSU MAM3184MC/MP User Manual
Page 133
C141-E134-01EN
A - 3
A.2
Locations of Connectors and Setting Terminals (MP model)
(Bottom view)
(Rear view)
Figure A.2
Locations of connectors and setting terminals (MP model)
CN1
CN2
Pin 34
Pin1
Pin A11
Pin A1
Pin 1
Pin 68
Pin 35
Pin A12
Pin A2
SCSI connector (CN1)
Connector for external operator panel (CN1)
Power connector (CN1)
