Add-on modules / Upgrading
24 D1859 (Econel 50)
Multifunctional expansion cards or expansion cards with integrated PCI-PCI bridge:
These expansion cards require up to four PCI interrupts: INT A, INT B, INT C, INT D. How many and
which of these interrupts are used is specified in the documentation provided with the card.
The assignment of the PCI interrupts to the IRQ Lines is shown in the following table:
Controller or slot INT
Mechanical slot
On board controller
1 2 3 4 5 6 7
USB 1.1 Slot PCI
PCI
INT
LINE
1 st 2 nd 3 rd 4 th
USB 2.0 SMBus
LAN
PCIe x
8
PCI Slot 1
PCIe x1
2 3 4 5
1 (A) – – – – – – A – C – – – –
2 (B) – – – – – – – B – D – – – A
3 (C) – – – – – – X – D A C A D B
4 (D) – – – – – X – – C B D B A C
5 (E) – – – X – – – – – – – – – –
6 (F) – – X – – – – – B – A C B D
7 (G) – X – – – – – – A – B D C –
8 (H) X – – – X – – – – – – – – –
Use first PCI/PCI Express slots that have a single PCI IRQ Line (no IRQ sharing). If you must use
another PCI/PCI Express slot with IRQ sharing, check whether the expansion card properly supports
IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on
this PCI IRQ Line must also support IRQ sharing.
