Internal ports and connectors
D1859 (Econel 50) 9
Internal ports and connectors
The positions of the internal ports and connectors are shown on the Cover. Additional information on
some ports is also provided here.
Hard disk connection
If you have connected hard disks to serial ATA (one hard disk is possible per serial ATA connection),
you must configure the respective settings in the BIOS Setup (further information you can find in the
BIOS Setup manual).
An ultra ATA/66 or ultra ATA/100 hard disk must be connected with a cable especially designed for
the ultra ATA/66 or ultra ATA/100 mode.
►
Connect the end of the cable marked with blue to the system board.
A serial ATA/150 hard disk must be connected with a serial ATA cable.
►
Connect the cable to the hard disk and to the connector on the system board.
