FS-8700-122 Profibus DP Master Manual Page 6 of 13
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
4.3 Client Side Connection Descript ors
Section Title
Connections
Column Title Function
Legal Values
Adapter Adapter Name Prof_DP
Example
// Client Side Connections
Adapters
Adapter
Prof_DP
4.4 Client Side Node Descriptors
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for Node
Up to 32 alphanumeric
characters
Node_ID Station address of physical remote Profibus Slave 0-125
Protocol Specify Protocol used Prof_Master
Example
// Client Side Nodes
Nodes
Node_Name , Node_ID , Protocol
PDP_SLV003 , 3 , Prof_Master
PDP_SLV125 , 125 , Prof_Master
