Right-click on the Profibus Slave and assign its Profibus address.
Continue adding all other Slaves and setting their Profibus addresses.
Right click on the ABM-DPV Master device and select Object Properties. Set the Master Station Address to the
same as the System_Station_Address used in the FieldServer’s config.csv file. Also set the desired Profibus
Network Baud rate.
Expand the Profibus DP tree and drag the
Slave Device you want to connect to onto
the Bus Configuration window. The
ANYBUS-S PDP Slave device is shown here
for illustration purposes
If your device is not listed, import the
device’s GSD file by right clicking on
Profibus DP and selecting “Install new GS*
file”.
