MIDI Implementation Chart/MMC List/Maintenance/Specifications

Maintenance

Specifications

Cleaning the exterior

* For normal cleaning, use a soft dry cloth

For stubborn dirt, moisten a cloth in diluted detergent, wring it out firmly, and wipe the dirt off.
Then polish with a dry cloth.
Never use solvents such as alcohol, thinner or benzene, since these will damage the printing and finish of the exterior.

* Mixer section

Connector

: 6mm Phone jack (x 2)

Input Impedance

: 20k ohm or higher

Reference Input Level

: -10dBV

Connector

: 6mm Phone jack (x 2)
: XLR-3-31 type (x 2)

Input Impedance

: 20k ohm or higher

Reference Input Level

: L: -50dBV, M: -30dBV,
L: -10dBV

Connector

: 6mm Phone jack (x 2)

Load Impedance

: 10k ohm or higher

Reference Output Level : -10dBV
Input Impedance

: 10k ohm or higher

Reference Input Level

: -10dBV

Connector

: 6mm Phone jack (x 2)

Load Impedance

: 10k ohm or higher

Reference Output Level : -10dBV

Connector

: 6mm Phone jack (x 4)

Input Impedance

: 8k ohm or higher

Reference Input Level

: -20dBV

Connector

: RCA pin jack (x 2)

Load Impedance

: 10k ohm or higher

Reference Output Level : -10dBV

Connector

: 6mm Phone jack (x 2)

Load Impedance

: 10k ohm or higher

Reference Output Level : -10dBV

Connector

: 6mm Stereo Phone jack

Load Impedance

: 16 ohm or higher

Connector

: RCA Pin jack (x 2)

Input Impedance

: 20k ohm or higher

Reference Input Level

: -10dBV

Connector

: Optical (x 2)

Format

: IEC 958 Part 3 (S/P DIF)

Connector

: DIN 5 pin

Format

: MIDI

Connector

: 6mm Phone jack (x 1)

(An optional FOOT SW Model 8051 can be connected.)

: 12kHz +/-15dB (Shelving Type)

MID

: 200Hz ~ 5kHz +/- 15dB (Parametric Type)

: 80Hz +/- 15dB (Shelving Type)

: 20Hz ~ 20kHz

* Recorder section

Recording Medium

: External SCSI device
(SCSI-2, asymmetrical transfer)
: Internal 2.5 inch hard disk (E-
IDE type)
: Connectable SCSI device: One

: FDMS-3*
(* Fostex Disk Management
System-3)

Normal Mode

: 4 Real track + 2 Additional
track (Sampling Rate: 32kHz/
DAC*)
(*) Digital Audio Acoustic
Coding)
