KEY
NO.
PART NO. DESCRIPTION
QTY.
1
108769-03 Extension Deflector
2
2
11201
Nut, #8-32 Hex Zinc.
2
3
11109
Screw, #8-32 x 1/2" PPH Zinc.
2
4
108425-01 Air Rod Retainer
1
5
108423-01 Panel Closure
2
6
11186
Screw, #8-32 x 1" PPH Zinc.
2
7
109098-01 Wire Assembly Electric Harness
1
8
108411-01 Air Separator
1
9
108434-01 Left Refractory, Std. Brick (B Models)
1
10
108432-01 Right Refractory, Std. Brick (B Models)
1
11
108430-01 Rear Refractory, Std. Brick (B Models)
1
12
108428-01 Bottom Front Refractory, Std. Brick
1
13
108426-01 Bottom Rear Refractory, Std. Brick
1
14
106683-01 Firebox Support Leg
2
15
24353
Box Assembly
1
16
108701-01 Screen Rod
2
17
108864-01 Strain Relief 1/2" Bushing
1
18
11165
Screw, #10 x 5/8 Mod. Tr. Blk. Ox
2
19
106703-02 Damper Door Assembly
1
20
108863-01 24" Supply Connect Plug
1
21
108412-01 Smoke Deflector
1
22
14253
Flexible Supply Line with Shutoff Valve
1
23
109040-01 Grate Assembly
1
24
108712-06 Burner Assembly
1
24-1 107742-03 Burner Pan
1
24-2 109037-01 Burner Tube
1
24-3 107748-01 Burner Bracket
1
24-4 107985-01 Pilot Shield
1
24-5 901681-01 Burner Clamp
1
24-6 11209
Nut, #10-24
1
24-7 11147
Screw, #10-24 x 1/2
1
24-8 901066-01 Brass Air Mixer (NG)
1
901066-02 Brass Air Mixer (LP)
1
24-9 901064-11 Injector (NG)
1
901065-09 Injector (LP)
1
24-10 108866-01 Pilot (NG)
1
24-11 108867-01 Pilot Orifice (LP)
1
24-12 11102
Screw, #8-32 x 3/8
2
25
14569
Electronic Gas Valve (NG)
1
14570
Electronic Gas Valve (LP)
1
26
107741-02 Valve Bracket
1
27
14129
Transformer
1
28
108368-01 3/8" Flex Line
1
29
11107
Screw, #10-32 x 1/4 PPH
4
30
108005-05 Wire Harness
1
31
11418
Push-On Nut
2
32
108440-01 Screen
2
33
14123
Strain Relief
1
34
14574
Limit Switch
1
35
22912
Draft Diverter
1
36
22084
Brick Liner Retainer
2
37
20042
Air Kit Cover
1
38
20088
Door Stop
1
39
20089
Pivot Clip
2
40
20090
Spring Clip
2
41
21171
Gas Knockout Cover
4
42
108652-01 Gas Conduit Assembly, Left
1
43
108654-01 Gas Conduit Assembly, Right
1
44
20280
Top Spacer
4
45
108415-01 Starter Pipe Collar
1
46
108417-01 5" Collar
1
47
14301
Ignition Module
1
PARTS AVAILABLE NOT SHOWN
901155-01 Vermiculite Bag
1
901156-01 Pan Material
1
901157-01 Lava Rock
1
PArts
MODELS P325E(B) AND VP325E(B)
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 20 of this manual.
