Hood
Latch
Slot
Hood
Latch
Slot
Hood
Tabs
• Insert the tabs on the hood into the slots in the front end of
the vehicle.
• Pull the hood forward and lower it closed.
Slot Slot
• Insert a hood latch into one of the slots in the front end of
the vehicle.
• Twist the base of the hood latch 1 /
4
turn to secure it in the
vehicle.
• Repeat this procedure to attach the other hood latch to the vehicle.
11
ASSEMBLY
F
13
H3427pr-0922
Grille
Tab
Tab
Slot
Slot
• Fit a lens assembly tab into the headlight slots in the grille.
• Press firmly to snap the lens assembly into the grille.
• Repeat this procedure to snap the other lens assembly into
the grille.
11
FRONT VIEW
Lens
Lens
Wide
Notch
Lens Guard Wide Tab
Lens Guard
• Fit the wide notch in the side of a headlight lens under the wide tab
on a lens guard.
• Press firmly on the inside of the headlight lens to snap it into the
lens guard.
• Repeat this procedure to assemble the other headlight lens to the
remaining lens guard.
