Outline of the M295 / M296
„
EmbedDed Audio Device – [Enabled] or [Disabled] SiS Embeded Audio (
SiS 7018 AC97 Audio )
„
Summary Screen – Select the display of configuration on Boot.
„
I/O Device Configuration – Lets you configure input/output device such
as Serial Port, Parallel Port, and Floppy disk controller.
P h o e n i x B I O S S e t u p U t i l i t y
Advanced
I/O Device Configuration Item Specific Help
Configure serial port
A using options:
Serial port A: [Auto]
Serial port B: [Enabled] [Disabled]
Mode: [Bi-directional] No configuration
Base I/O address/IRQ [2F8]
Parallel port: [Enabled] [Enabled]
Mode: [Bi-directional] User configuration
[Auto]
BIOS or OS chooses
configuration
(OS Controlled)
Displayed when
Controlled by OS
F1 Help K‚ Select Item -/+ Change Values F9 Setup Defaults
Esc Exit
st
Select Menu Enter Select Sub-Menu F10 Save and Exit
Figure 1-15 I/O Device Configuration Sub-Menu
Serial port A [Disabled] / [Enabled]
/ [Auto] Configure serial port A using options:
Disabled - No configuration,
Enabled - User configuration,
Auto - BIOS or OS configuration.
(OS Controlled) – Displayed when
controlled by OS
Serial port B [Disabled] /
[Enabled] / [Auto] Configure serial port A using options:
Disabled - No configuration,
Enabled - User configuration,
Auto - BIOS or OS configuration.
(OS Controlled) – Displayed when
controlled by OS
Mode: [IrDA] [FIR] Enabled the IrDA transmission
Base I/O address/IRQ [3F8] / [2F8] / [3E8] /
[2E8] Set the base I/O address and IRQ for
serial port B.
FIC M295 / M296 Service Manual 1-25
