Festool Kapex KS 120 - Manual (Page 7)

Functional Description (continued)
Item Name or Description Ref. Page(s)
A Bevel Gauge and Pointer (both sides) 12, 18
I Trigger Lock 9, 10, 11
J Power Switch/Trigger 9, 10, 11
K Main Handle 11, 17
L Laser Dust Lens 28
M Blade Guard 9
N Miter Stop Release Lever 12, 15, 18, 20
O Miter Lock Lever 12, 15, 18, 20
R Bevel Adjustment Knob 12, 18
Item Name or Description Ref. Page(s)
S Speed Control Dial (see inset) 11
T Laser On/Off Button (see inset) 11
U Depth Limit Adjustment Knob 13
V Slide Lock Knob 10
W Head Lock Knob 10
X Auxiliary Fence 13
Y Main Fence 13, 23
Z Table Inserts 23
Supplemental User’s Manual 7
