What are ASEs?
ASEs (Analysis Service Elements) are data
collection and network performance monitor-
ing hardware devices placed on a wide area
network (WAN) or Local Area Network (LAN)
as part of the Visual UpTime Select system,
which offers in-depth, real-time, and historical
visibility into the performance of your
applications infrastructure. In the system,
data gathered by ASEs is stored in the Visual
UpTime Select server and displayed and ana-
lyzed from the Visual UpTime Select Web client.
As a service level management tool, ASEs
indicate when services are being met, provide
warnings when services start to degrade, and
send alerts when services are not met.
Hardware Warranties
Enhanced Gold, Bronze, and International
Gold ASE hardware warranty service programs
are available to help you maximize your
investment in Visual UpTime Select. For more
detailed warranty information, visit:
www.fl ukenetworks.com/visualcustomercare
Ordering Information
For more details, please contact your Visual
UpTime Select authorized reseller or
Fluke Networks Sales at (800) 240-4010
or (301) 296-2300.
HSSI inline probe ASE specifcations
General Dimensions 17.3” (43.9 cm) x 12” (30.5 cm) x 3.5” (8.9 cm)
Weight 10.45 lbs.
Data Rate 0 to 44.736 Mbps synchronous
Timing Mode RD: Always synchronous with SCR
SD: Synchronous with SCT or SCTE
Environment Operating Temperature 0
o
to +40
o
C (+32
o
to +104
o
F)
Storage Temperature -20
o
to +55
o
C (-4
o
to +131
o
×F)
Clearance Requirement Minimum of 3” (7.62 cm) space on sides.
Operating and Storage
Humidity 10% to 80%, noncondensing
Power Requirements Input 100 to 240 VAC
Frequency 50/60 Hz
Input Current Rating 1 amp
HSSI Interface Confi guration Two HSSI interfaces: one DTE and one DCE for
monitoring to-network and from-network traffi c.
Serial Port Interface Baud Rate 19200 or 9600 bps
Parity 8 data bits, no parity
Stop Bit 1 stop bit
Electrical Format EIA RS-232, DTE
Connector 9-pin D, male per EIA-574
Ethernet 10/100BaseT
Interface Bite Rate 10 or 100 Mbps
Connector 8-pin modular jack: RJ-48
