DRIVER SCOPE OF SUPPLY 2
2.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies PART # Description
FS-8917-03
RJ45 to DB9F connector adapter
FS-8917-16 Pigtail cable for RJ45 Port for RS-232 use
2.2 Provided by the Supplier of 3rd Party Equipment
2.2.1 Hardware
Part # Description
Siemens MXL/XLS System
Siemens NIM-1R Network Interface Module ( for MXL usage )
Siemens RPM Network Interface Module ( for XLS usage )
500-699103 Siemens NIM-1W Network Interface Module ( for MXL usage )
Siemens Cable P/N 555-193085 (For RS-232 connection)
2.2.2 Required 3
r d
Party Configuration
The SBT-FSI System must be set up for remote monitoring with the MXL or XLS to foreign systems protocol.
The ports on the RPM must be configured by the XLS panel. The RPM can be configured for RS-232 or RS-485,
but not both together. Connection to the RS-485 port has not been tested and is not supported.
