FS-8700-40 SBT FSI Driver Manual Page 28 of 32
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix A.7. Request % Compensation Used / % Dirty
Data_Arrays
Data_Array_Name , Data_Format , Data_Array_Length
Comp_Used
, Uint16 , 253
Dirty , Uint16 , 253
Map_Descriptors
Map_Descriptor_Name , Scan_Interval , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Block_Number , Length , Msg_Type
PNL_1_Comp_Used , 300s
, Comp_Used , 0 , Rdbc , Panel1 , 1 , 253 , Compensation_Used
PNL_1_Dirty , 300s , Dirty , 0 , Rdbc , Panel1 , 2 , 253 , Dirty
Appendix A.8. Opcode 45 – Request List Map Descriptors that trigger at Startup or Node Offline and stop at Node Online
Request List Map Descriptors can be added to ensure the current alarm, trouble, supervision, security or status events that have not been cleared or reset in
the remote panel are recorded again after a power-cycle or a re-connection to the panel. Request List Map Descriptors are optional and may be defined per
type as needed.
A Passive Map Descriptor of the indicated type needs to be defined and linked to the Request List Map Descriptors to allow storage of these events.
Map_Descriptors
Map_Descriptor_Name , Scan_Interval , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Block_Number , Length , Msg_Type
PNL_1_Req_List_ALR , 2.0s , - , 0 , ARS , Panel1 , - , 1 , req_list_alarm
PNL_1_Req_List_TRB , 2.0s , - , 0 , ARS , Panel1 , - , 1 , req_list_trouble
PNL_1_Req_List_SUP , 2.0s , - , 0 , ARS , Panel1 , - , 1 , req_list_superv
PNL_1_Req_List_SEC , 2.0s , - , 0 , ARS , Panel1 , - , 1 , req_list_secur
PNL_1_Req_List_STA , 2.0s , - , 0 , ARS , Panel1 , - , 1 , req_list_status
// for networked panels
PNL_2_Req_List_ALR , 2.0s , - , 0 , ARS , Panel2 , - , 1 , req_list_alarm
PNL_2_Req_List_TRB , 2.0s , - , 0 , ARS , Panel2 , - , 1 , req_list_trouble
PNL_2_Req_List_SUP , 2.0s , - , 0 , ARS , Panel2 , - , 1 , req_list_superv
PNL_2_Req_List_SEC , 2.0s , - , 0 , ARS , Panel2 , - , 1 , req_list_secur
PNL_2_Req_List_STA , 2.0s , - , 0 , ARS , Panel2 , - , 1 , req_list_status
Data values will be stored for
device addresses from 0 to
Length which can be from 1
to 253
Block_Number sets the
module number for which this
analog device data pertains
(must be DLC or ALD)
The data values stored are %
values per device address,
e.g. 1, 10 etc
