FS-8700-40 SBT FSI Driver Manual Page 27 of 32
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix A.6. Request ASD or Sensitivity
Data_Arrays
Data_Array_Name , Data_Format , Data_Array_Length
Current_ASD
, Uint16 , 60
Current_Sens , Uint16 , 60
Map_Descriptors
Map_Descriptor_Name , Scan_Interval , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Block_Number , Length , Msg_Type
PNL_1_ASD
, 300s , Current_ASD , 0 , Rdbc , Panel1 , 1 , 60 , Current_ASD
PNL_1_Sens , 300s , Current_Sens , 0 , Rdbc , Panel1 , 2 , 60 , Current_Sensitivity
The values stored are as follows:
Current_ASD Current_Sensitivity
0 does not apply does not apply
1 disabled 2.45%/foot
2 office 2.59%/foot
3 warehouse 2.72%/foot
4 lobby 2.86%/foot
5 computer room 3.00%/foot
6 dormitory 3.13%/foot
7 health care 3.27%/foot
8 garage
9 utility room
10 precious storage
11 hostile environment
Block_Number sets the
module number for which this
analog device data pertains
Data values will be stored for
device addresses from 0 to
Length which can be from 1
to 253
