5.2 Client Side Node Parameters
Section Title
Nodes
Column Title Function
Legal Values
Node_Name Provide name for Node Up to 32 alphanumeric characters
Node_ID Panel number 1-999
Protocol Specify protocol used Cerberus, SBT-FSI
Port
Specify on which port the device is connected to the
FieldServer
P1-P8, R1-R2
1
Example
// Client Side Nodes
Nodes
Node_Name , Node_ID , Protocol , Port
Panel1
, 1 , SBT-FSI , P1
5.3 Client Side Map Descriptor Parameters
5.3.1 FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where
data is to be stored in the
FieldServer
One of the Data Array names from Section 4.
Data_Array_Offset Starting location in Data Array 0 to (Data_Array_Length-1) as specified in Section 4.
Function
Function of Client Map
Descriptor
Rdbc for Msg_Type:
Poller, Analog_Volts, Analog_Sense, Analog_Thres
Passive for Msg_Type:
Fire_Alarm, Fire_Ack, Trouble, Trouble_Ack, Secur,
Secur_Ack, Super, Super_Ack, Status, Test, Audible,
Reset
Awt for Msg_Type:
Entity_Arm_Disarm; Entity_Activate_Deact
