5.3.2 Driver Related Map Descriptor Parameters
Column Title Function Legal Values
Node_Name
Name of Node to fetch or store
data from
One of the Node names specified in Section 5.2
Block_Number
Starting module number within
panel. There are 256 points per
module.
1 – 256
Sub_Module
Sub module number for XLS
systems only
0 – 99
Component_Address
Component address for XLS
systems only
0 – 99
Length
Length of Map Descriptor
specifies number of points. There
are 256 points per module. 1 – 10000
Msg_Type
Indicates a “poller” Map
Descriptor or identifies the type
of event message this Map
Descriptor will handle. If this is
configured, the driver will store a
value that indicates the point type
of the event if the Data Array
used on the Map Descriptor is not
of a bit type
Poller; Fire_Alarm; Fire_Ack; Trouble; Trouble_Ack;
Super; Super_Ack; Secur; Secur_Ack; Status; Test;
Audible;
Reset; Analog_Volts; Analog_Sense;
Analog_Thres; Entity_Arm_Disarm
8
;
Entity_Activate_Deact 9
Analog_Device
Indicates range of device data to
be requested by analogs
0 : devices 1-60
1 : devices 61-121
2 : devices 122-182
3 : devices 183-243
4 : devices 244-252
Block_Offset
This field allows you to set the
start address of a MXL or XLS
point in a Map Descriptor.
0 - 255
Entity_Types
Used to indicate the type of Entity
on the panel.. . Refer to Appendix
A.5 for more information Inputs, Outputs, (If all elements are Input or Output)
OR specify each element of the entity individually
e.g. IOIOIOO
Entity_Energizations
Used to control the entity on the
panel. Refer to Appendix A.5 for
more information.
De-energize, Energize, (If all elements are Energize
or De-energize)
OR specify each element of the entity individually,
e.g. EDED---DED
5.3.3 Timing Parameters
Column Title Function Legal Values
Scan_Interval* Rate at which data is polled ≥0.001s , 1.0s
8 Refer to Appendix A.5
9 Refer to Appendix A.4
