8 power unit – FUJITSU 16ADV User Manual
Page 31
Index
No.
Composition
& Quantity
S
P
Remarks
AC(V)
120
Parts name
(Description)
220
~240
Specification
3 - 19
3.8 Power Unit
1~
00
1
CA04291-F544
POWER UNIT
√
100-120V
1
CA04291-F545
POWER UNIT
√
220-240V
1
1
CA02758-G135
PB COVER
√
√
2
1
✽
CA02951-4262
POWER BOARD
√
100-120V
1
✽
CA02951-4267
POWER BOARD
√
220-240V
3
5
@
CA02758-0197
TAPPING SCREW
√
√
4
1
@
F6-SW2N3-06121
SCREW
√
√
5
1
@
CA02758-Y137
SWITCH COVER
√
√
6
1
CA02758-Y655
SENSOR LEVER 5
√
√
7~20
1
CA04040-F590
PAPER FRAME ASY
√
√
7
1
CA02758-Y675
PAPER FRAME
√
√
8
1
CA02758-Y679
SENSOR LEVER 6
√
√
9
1
CA04040-G591
EJECT ROLLER
√
√
10
1
CA04040-Y592
ER BEARING
√
√
11
1
CA04040-0590
ONE WAY CLUTCH
√
√
12
1
CA02758-Y676
SIDE FRAME LP
√
√
13~17
1
@
CA02758-F671
PAPER GUIDE ASY
√
√
13
1
CA02758-Y670-TK
PAPER GUIDE
√
√
14~15
1
CA02758-G673
FEED 1 ASY
√
√
14
1
CA04040-Y672
FEED SPRING 1
√
√
15
1
CA02758-Y673
PINCH ROLLER
√
√
16
1
CA02758-Z671
STACK LEVER
√
√
17
1
CA02758-Y671
P LABEL
√
√
18
1
CA02758-Y677
SIDE FRAME RP
√
√
19
6
@
F6-SN2TP3-08
TAPPING SCREW
√
√
20
1
CA02758-G678
SWITCH ASY
√
√
21
1
@
CA02758-Y661
GEAR 1
√
√
22
3
@
CA02758-Y662
GEAR 2
√
√
23
1
@
CA02758-Y663
GEAR 3
√
√
24
1
@
CA02758-Y664
GEAR 4
√
√
25
1
@
CA02758-Y665
GEAR 5
√
√
26
1
@
CA02758-Y668
FAN BRACKET
√
√
27
1
✽
CA02758-G128
FAN ASY
√
√
28
2
@
F6-SW2N3-20111
SCREW
√
√
29
2
@
CA02758-0195
TAPPING SCREW
√
√
30
4
CA02358-Y291
DAMPER MM
√
√
