1 - 1
1. HOW TO REFER TO THIS MANUAL
Example:
Index
No.
Composition
& Quantity
S
P Specification Parts name
(Description)
Remarks
(1) This figure shows the index number of the part in the drawing .
(2) These columns show the construction levels. A higher level part consists of the following lower level
parts listed until the quantity of the next part appears at the same level. See example e .
(3) m-n shows an assembly or unit consisting of more than one part.
(4) These parts are at the same level and belong to the same upper level part.
(5) Parts with on asterisk(✽) are recommended spare parts.
(6) The Sensor Lever is the part name of the item number 10.
(7) Parts with an at (@) can be bought.
Parts with no marks cannot be bought.
✽ The Stepping Motor is a recommended spare part.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
1~42 1 CA04040-G102 BASE FRAME ASY
1~24 1 CA04040-G103 BASE FRAME S ASY
1 1 CA04040-G104 FRAME ASY
2~ 6 1 CA04040-G260 M BRACKET ASY
2 1 @
CA04040-G261 M BRACKET S ASY
3 1 ✽ CA04040-0260 STEPPING MOTOR
4 2 @ F6-SW2N3-06111 SCREW
5 1 @ CA04040-Y263 GEAR V
6 1 @ CA04040-Y265 GEAR W
7 2 @ F6-SW2N3-06111 SCREW
8 1 @ CA04040-Y267 GEAR X
9 1 @ CA04040-Y269 GEAR Y
10 1 @ CA04040-Y145 SENSOR LEVER
11~13 1 CA04040-G275 SIDE GUIDE L ASY
11 1 CA04040-Y276 SIDE GUIDE L
12 1 CA04040-Y277 RACK L
13 1 @
F6-SN2TP3-05 TAPPING SCREW
14~17 1 CA04040-G278 SIDE GUIDE R ASY
