Index
No.
Composition
& Quantity
S
P Remarks
AC(V)
120
Parts name
(Description) 220
~240
Specification
3 - 17
3.7 Laser Diode Stay
1~18 1 CA04291-G525 LD STAY ASY
√ √
1 1 CA04040-Y540 LD STAY
√ √
2 1 ✽ CA04280-E010 LD UNIT
√ √
No.3 deleted
4 3 @ F6-SW2N3-08111 SCREW
√ √
5~6 1 @ CA02758-G123 DCH LED UNIT
√ √
5 1 CA02758-0123 DCH LED
√ √
6 1 CA02758-Y124 LED HOLDER
√ √
7~16 1 ✽ CA04291-F680 FRAME 2 ASY √ √
7 1 CA02758-Y680 PAPER FRAME 2
√ √
8~9 2 CA02758-G682 FEED 2 ASY
√ √
8 1 CA02758-Y682 FEED SPRING 2
√ √
9 1 CA02758-Y673 PINCH ROLLER
√ √
10~11 1 CA04291-F690 GUIDE ASY
√ √
10 1 @ CA02758-Y690 ROLLER GUIDE √ √
11 1 @ CA04291-G692 ROLLER ASY
√ √
12 1 @ CA02758-Y684 GEAR 6
√ √
13 1 @ CA02758-G685 GEAR 7 ASY
√ √
14 1 @ CA98001-5552 TIMING BELT
√ √
15 1 @ CA02758-Y688 GEAR COVER
√ √
16 1 @ CA02758-Y592 LABEL √ √ CAUTION
17 1 @ CA02758-Y591 LABEL
√ √
CAUTION
18 1 @ CA04040-G154 CL GUIDE ASY
√ √
19 1 CA04040-Y530 LS DUCT
√ √
20 1 CA04040-G587 PARTITION ASY √ √
21 2 F6-SW2N3-08111 SCREW
√ √
22 1 CA04040-Y531 F FILM
√ √
23 1 CA04040-Y532 LS FILM
√ √
