E-2
ACCESSORIES
CHECKING ACCESSORIES
CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT
Carefully check the terminals for position and type before making any connections.
Loose connectors can result in picture or color problems. Make sure that all connectors are securely inserted into their terminals.
Ferrite cores
These ferrite cores are used to attenuate undesired signals.
Two big ferrite cores
When connecting a cable to the power input terminal, RS-232C terminal, attach one of these ferrite cores to the cable near the terminal.
Two small ferrite cores
When connecting a cable to the external speaker output terminal attach one of these ferrite cores to the cable near the terminal.
RS-232C Cable
Ferrite Core
Power Cable
Ferrite Core
Ferrite Core Ferrite Core
One power cable Two user’s manuals Two AA batteries One remote control Two big ferrite
cores
Two small ferrite
cores
