English
E-7
SATELLITE TUNER
• Connect the video signal cable to the component video input terminal, S-video input terminal, or the video input terminal.
• If the component to be connected is equipped with component video output terminal, it is recommended to connect to the component video
terminal.
DVD PLAYER
• Connect the video signal cable to the component video input terminal, S-video input terminal, or the video input terminal.
• If the component to be connected is equipped with component video output terminal, it is recommended to connect to the component video
terminal.
To S-video output
To component video output
To video output
To audio outputs
To audio
inputs
To video input
To component
video input
To S-video input
To S-video output
To component video output
To video output
To audio outputs
To audio
inputs
To video input
To component
video input
To S-video input
Bottom of Display
Bottom of Display
