E-6
CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT (Continued)
VCR
• Connect the video signal cable to either the S-video input terminal or the video input terminal.
To video output
To video input
Bottom of Display
Note
• Unplug the power cord from the AC outlet before you connect external components.
• Also refer to the instructions for the component to be connected.
* When inputting voice see “Selecting input terminals (page E-30)”
* Terminal layout may differ and functions may not be available with some models and some device options.
To S-video output
To audio outputs
To audio inputs
To S-video input
