English • 5
5. Install Oven
1. Slide oven into cabinet cutout.
2. Push straight in until oven trim is fl ush with
cabinet wall, being careful not to crimp fl exible con -
duit between oven and cabinet back wall. The oven
should be straight, not crooked.
3. Install 2 screws through tap holes in trim.
Final Steps
Step 5 and 6: Install Oven and Test Operation
C60T265A6 12/1/06 17:34 Página 7
6. Test Operation
1. Verify that all control knobs are in the OFF position.
2. Turn on power at the breaker.
The oven will beep and the clock will appear in the
display. The lock icons in the display will blink on
and off and you will hear a series of clicks as the
oven performs a system check.
When successfully completed, only the clock time
will appear in the display. The clock is preset to 12:00
AM.
3. Check power at junction box using a volt meter.
For 240 V installation, the reading between the red
and black wires (line to line) should be 220 to 240
volts.
For 208 V installation, the reading between the red
and black wires (line to line) should be 190 to 208
volts.
4. Test the oven mode.
Turn cooking mode selector knob to BAKE. The
following should occur:
• 350 °F (the default baking temperature) and
COOK appear in the display.
• Red preheat indicator lights up.
• Oven light and fan turn on.
5. If any of the tests do not result as explained above,
contact with our authorised Thecnical Service.
Otherwise, the installation is complete at this time.
