8
IMPORT ANT
A 25 AMP FUSE MUST BE INST ALLED IN TOP
OF BA TTER Y BEFORE
TOY WILL RECHARGE OR OPERA TE
®
Battery Charging
®
• Plug the charger into a standard 120 volt wall outlet.
Note: If power flow to the wall outlet is controlled by a
switch, make sure the switch is ON.
• Before first time use, charge the battery for at least 18
hours. Never charge the battery longer than 30 hours.
Note: The battery must be upright while charging.
• Recharge the battery after each use of your vehicle for at
least 14 hours. Do not charge the battery longer than
30 hours.
• Once the battery is charged, disconnect the charger
connector from the battery connector. Unplug the charger
from the wall outlet. The battery is now ready to be
installed in your vehicle. Please see “Battery Installation”
on page 15 for detailed instructions on installing your
battery. If your battery is already installed in your vehicle,
simply re-connect the battery connector and motor
harness connector and re-assemble the seat.
• If you are charging the battery for the first time, insert a
thermal fuse into the battery. The battery will not charge
unless a thermal fuse is installed.
• If you are recharging your battery, make sure the thermal
fuse already installed in the battery is in good condition.
Remove the fuse from the battery and shake it gently. If it
rattles, it is damaged. Replace a damaged fuse with a
new Power Wheels
® thermal fuse.
Thermal
Fuse
1
3
®
• Squeeze the Lock-In connector tabs on the charger
connector and plug it into the battery connector.
IMPORTANT NOTE! If you are recharging your battery,
you will first need to disconnect the battery connector
from the motor harness connector under the seat of
your vehicle.
Battery
Connector
Charger
Connector
Lock-In
Connector
Tabs
Charger
2
