IMPORTANT A 25 AM P F US E M US T BE INS TA LLED IN TO P OF B ATTE RY B EFO RE TO Y WILL RE CH AR GE OR OP ER ATE
®
1. Vehicle Body
2. Long Axle
3. Wheel - 2
4. Pivot Wheel
5. Pivot Axle
6. Right Shifter
7. Left Shifter
8. .354 (Small Diameter) Cap Nut - 2
9. Wire Retainer - 4
10. Driver - 2
11. Seat
12. Retainer Straps - 2 Sets
(Seat Belt and Battery)
13. 6 Volt Battery
14. Hex Bushing - 2
15. #12 x 1
1 /
2
" Screw
16. Metal Bracket
17. Round Bushing - 3
18. 5 /
16
" (Small Diameter) Washer - 2
19. Thermal Fuse
20. #8 x 1" Screw - 12
21. Skid Guard
22.
7 /
16
" (Large Diameter) Washer - 2
23. .437 (Large Diameter) Cap Nut - 2
Not Shown
Label Sheet
6 Volt Charger
Parts Diagram
