2. VIDEO PLOTTER
2-11
2.5 Marks, Lines
2.5.1 Entering mark
You can inscribe marks on the display to denote important points, for example, a
buoy or a wreck. The mark memory capacity is 6,000 points.(20 types mark and
lines).
Selecting method of entry
Marks can be entered by cursor position, L/L or own ship’s position.
1. Press the [NAV MENU], [0] key to show VIDEO PLOTTER 2 menu.
[VIDEO PLOTTER 2]
1 [VIDEO PLOTTER 1]
2 NAV DATA POSN
3 ALIGN + CURSOR
OFF/ON
5 MARK ENTRY MODE
CURSOR/L/L/OWN SHIP
Video plotter 2 menu
2. Press the [5] key several times to select CURSOR, L/L or OWN SHIP.
3. Press the [ENTER] key.
4. Press the MARK key, and select the mark shape.
CURSOR; enters the mark at the cursor position. Operate the trackball to
select the position and then press the [ENTER] key.
L/L; After selecting L/L, the latitude/longitude field appears above ENTER
MARK menu by pressing the [MARK] key. Press the numeric key to enter the
L/L values which you want to enter the mark, and then press the [ENTER]
key.
OWN SHIP;
The mark is entered at the own ship’s position anytime the
[ENTER] key is pressed.
