8
L i f e B o o k E S e r i e s B I O S
Secondary Master Submenu of the Main Menu
The Secondary Master submenu allows you to configure
secondary ATA devices.
Figure 3. Secondary Master Submenu
Table 3: Fields, Options and Defaults for the Secondary Master Submenu of the Main Menu
Menu Field Options Default Description
Type: ■ Auto
■ None
■ CD-ROM
■ SuperDisk
■ Hard Disk
[Auto] Selects the ATA/ATAPI device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all
of the following Set-up items do not appear. Select CD-ROM,
SuperDisk or Hard Disk for appropriate drive type installed at
this connection.
Multi-Sector
Transfers: ■ Disabled
■ 2 Sectors
■ 4 Sectors
■ 8 Sectors
■ 16 Sectors
■ 32 Sectors
■ 64 Sectors
■ 128 Sectors
[Disabled] This option cannot be changed when Auto is selected. Specify the
number of sectors per block for multiple sector transfer.
LBA Mode Con-
trol: ■ Disabled
■ Enabled
[Disabled] Enables or disables Logical Block Addressing in place of Cylinder,
Head, Sector addressing. This option cannot be changed when
Auto is selected.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu -/Space
Enter F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select ATA/ATAPI drive
installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
Except [Auto]
You enter parameters of
the drive.
[None]
The drive is disabled.
Secondary Master [MATSHITADVD-ROM SR-8175-(SM)]
Type: [ Auto ]
Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
PIO Transfer Mode: [Standard]
DMA Transfer Mode: [Disabled]
▲
