6
L i f e B o o k E S e r i e s B I O S
Primary Master Submenu of the Main Menu
The Primary Master submenu identifies what ATA
devices are installed.
Figure 2. Primary Master Submenu
Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu
Menu Field
Options
Default
Description
Type:
■
Auto
■
None
■
CD-ROM
■
SuperDisk
■
Hard Disk
[Auto]
Selects the ATA/ATAPI device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all
of the following Set-up items do not appear. Select CD-ROM if a
CD-ROM drive is installed at this connection. If Hard Disk is
selected, you must specify the number of Cylinders, Heads, and
Sectors for the drive.
Cylinders:
■
A number
between 0
and 65,535
–—
This item appears only when Hard Disk is selected as the type. This
field is changed by incrementing (pressing the [Spacebar]) or by
typing in the number.
Heads:
■
A number
between 1
and 16
–—
This item appears only when Hard Disk is selected as type. You can
change the value by incrementing (pressing the [Spacebar]) or by
typing in the number.
Sectors:
■
A number
between 0
and 63
–—
This item appears only when Hard Disk is selected as type. You can
change the value by incrementing (pressing the [Spacebar]) or by
typing in the number.
PhoenixBIOS Setup Utility
F1
Help
ESC
Exit
Select Item
Select Menu
-/Space
Enter
F9
Setup Defaults
F10
Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select ATA/ATAPI drive
installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
Except [Auto]
You enter parameters of
the drive.
[None]
The drive is disabled.
Primary Master [FUJITSU MHH2064AT-(PM)]
Type:
Auto
]
Maximum Capacity:
20004MB
Multi-Sector Transfers:
[16 Sectors]
LBA Mode Control:
[Enabled]
PIO Transfer Mode:
[Fast PIO 4]
DMA Transfer Mode:
[Ultra DMA 4]
▲
