STARTERKIT MB91360
Chapter 6 Evaluation Board Hardware
UG-910006-13 - 28 - © Fujitsu Microelectronics Europe GmbH
Jumper Pin-No. Pin Name IO-Port Resource Function
162 PWM1P0 PR0 SMC 0
163 PWM1M0 PR1 SMC 0
164 PWM2P0 PR2 SMC 0
165 PWM2M0 PR3 SMC 0
166 HVDD - SMC Driver Vdd
167 PWM1P1 PR4 SMC 1
168 PWM1M1 PR5 SMC 1
169 PWM2P1 PR6 SMC 1
170 PWM2M1 PR7 SMC 1
171 HVSS - SMC Driver Vss
172 PWM1P2 PS0 SMC 2
173 PWM1M2 PS1 SMC 2
174 PWM2P2 PS2 SMC 2
175 PWM2M2 PS3 SMC 2
177 PWM1P3 PS4 SMC 3
178 PWM1M3 PS5 SMC 3
179 PWM2P3 PS6 SMC 3
180 PWM2M3 PS7 SMC 3
Table 3: Overview of available resource-functions and IO-ports on jumpers
