Evaluation board hardware, Board components, 6 evaluation board hardware – FUJITSU MB91360 User Manual
Page 22: 1 board components
STARTERKIT MB91360
Chapter 6 Evaluation Board Hardware
UG-910006-13
- 22 -
© Fujitsu Microelectronics Europe GmbH
6 Evaluation Board Hardware
6.1 Board
Components
Socket QFP208 for
Microcontroller
MB91F361/2
Monitor UART and
RS232-connector
DC input
On/Off
512k SRAM
Oscillators
PAL
User buttons on
external Ints 0,1
Mode
LCD
Prototyping
CAN line slew rate
CAN
tranceiver and
RS232 driver
and connector
User-LEDs on
Port J
5V Regulator
LCD on Port
JP15 : PWM and
Pulsgen. outputs
JP25 :
Addressbus and
JP24 : Databus
JP16 : Analog
Ports (AD/DA)
JP20 : INTs,
ICU and
JP14 : Serial
Interfaces
Power-on LED
Reset Circuit and
Reset-LED
MCU
