FUJITSU PDS4207W-H - Manual (Page 15)

15
ENGLISH
RGB 1
PREPARATION
Switch on the main power switch.
Press the main POWER SWITCH at the rear. The power lamp lights (red).
Pressing this switch again switches off the power.
BASIC OPERATIONS
Mode display
• COMP.VIDEO stands for component video mode.
• When the speaker setting (see p.21) is OFF, SPEAKER OFF will be displayed if the VOLUME button is pressed.
Example: VIDEO mode
Example: When RGB 1
selected
Mode display
1
Press the POWER button.
The power lamp changes from red
to green.
2
Select the video mode.
Select the video mode with the
MODE button.
Pressing the MODE button moves
the mode to the next item as be-
low.
∗
Adjusting the volume
Use the VOLUME buttons to adjust the
volume .
+ button····Raises the volume.
– button····Lowers the volume.
∗
The current volume setting is memo-
rized even when the power is
switched off.
VIDEO
RGB 1 RGB 2 VIDEO
COMP. VIDEO S-VIDEO
∗
This operation can also be done
using the buttons on the Display’s
operation panel.
