35
ENGLISH
ADJUSTMENT ITEM LIST (ADJUSTMENT CRITERIA)
VERTICAL POSITION
When too low····Adjust with the button.
When too high····Adjust with the button.
The adjustment range is from –250 through +250.
HEIGHT
When too small····Adjust with the button.
When too large····Adjust with the button.
The adjustment range is from –150 through +150.
HORIZONTAL POSITION
When too far left····Adjust with the button.
When too far right····Adjust with the button.
The adjustment range is from –250 through +250.
HORIZONTAL WIDTH
When too small····Adjust with the button.
When too large····Adjust with the button.
The adjustment range is from –150 through +150.
VERTICAL LINE
The number of vertical lines on the screen can be set.
With the ADJUST button, select the number of vertical lines.
Pressing the ADJUST button moves the selection to the next item as be-
low.
VERTICAL POSITION
0
MENU RETURN
ADJUST
SET NEXT
HORIZONTAL WIDTH
0
MENU RETURN
ADJUST
SET NEXT
Adjustment items
• Pressing the SET button moves selection to the next item.
• After adjustment, the screen may be jumbled. If so, return the setting to the original adjustment value.
• The RGB mode means both RGB 1 and RGB 2 modes.
If there is no operation for 60 seconds, the screen display goes off.
HEIGHT
0
MENU RETURN
ADJUST
SET NEXT
HORIZONTAL POSITION
0
MENU RETURN
ADJUST
SET NEXT
VERTICAL LINE
480 LINES
MENU RETURN
SELECT
SET NEXT
480LINES 400LINES
350LINES
