DIGITAL DISPLAYS
Course
123 °
COURSE
Depth
32.8
ft
DEPTH
Heading TRUE/MAG#
318 °
HEADING
Odometer
56
nm
ODOMETER
Position GPS 3D
30
°
00.065'N
130
°
00.574'E
POSITION
Temperature
69.8
°
F
WATER TEMPERATURE
Trip meter
12.1
nm
TRIP DISTANCE
Time to Go
00
H
30
M
TIME-TO-GO
1018
hpa
AIR PRESSURE
Air Pressure
Speed
19.3
kt
SPEED
Rng
1.21
nm
RANGE & BEARING
Brg
140 °
Wind Speed APP*
8.0
m/s
WIND SPEED
Wind Dir. APP*
138 °
WIND DIRECTION
*: APP or TRUE, depending
on menu setting.
#: TRUE or MAG depending
on menu setting.
&: To destination waypoint
Note 1: Nav data is updated with some
delay.
Note 2: When data is lost 120 sec., the
display shows "- -" at the location
where data is lost.
= GPS receiving status (Displays when
connecting with GP-310B/320B and "In/Out"
is selected at the Installation menu.)
NO FIX: Position cannot be found.
GPS 2D: 2D (dimension) GPS position fix
GPS 3D: 3D GPS fix
GPS W2D: 2D WAAS position fix
GPS W3D: 3D WAAS position fix
NAV data display-2
1.17 Other Menu Items
This section describes the menu items
not previously mentioned.
Page 1
HUE (Picture Color)
Two picture color arrangements are
available: Day and Night. Day shows
echoes on a white background; Night
shows them on a black background.
1. Press the [MENU/ESC] key to
display the menu.
2. Use ▲ or ▼ to choose HUE from
page 1 of the menu.
3. Press ► to show the options
window.
4. Use ▲ or ▼ to choose Day or Night
as appropriate.
5. Press the [MENU/ESC] key to close
the menu.
WHITE LINE
The white line feature displays the
leading edge of the bottom echo in
white. This is useful for discriminating
bottom fish near the bottom.
1. Press the [MENU/ESC] key to
display the main menu.
2. Use ▲ or ▼ to choose WHITE LINE
from page 1 of the menu.
3. Press ► to show the options
window.
