5 Broadcom Advanced Control Suite 2 (BACS2)
165
E
5.4.2 Resources
The following information can be checked on the "Resources" tab.
` Some information may not be available for all network adapters.
Item Description
Bus Type The type of input/output (I/O) interconnect used by the adapter
Bridge The bridge type, which is the PCI-E to PCI-X bridge.
Bridge Lanes The number of PCI-E lanes connected to the bridge.
Bridge Speed The clock speed on PCI-E bus.
Slot No The slot number on the system board occupied by the adapter.
Bus Speed (MHz) The bus clock signal frequency used by the adapter.
Bus Width (bit) The number of bits that the bus can transfer at a single time to and from the
adapter.
Bus No Indicates the number of the bus in which the adapter is installed
Device No The number assigned to the adapter by the operating system
Function No The port number of the adapter. For a single-port adapter, the function number
is 0. For a two-port adapter, the function number for the first port is 0, and the
function number for the second port is 1.
Interrupt Request The interrupt line number that is associated with the adapter. Valid numbers
range from 2 to 25.
Memory Address The memory mapped address that is assigned to the adapter. This value can
never be 0.
