Page 5

background image

5

OPTIONALLY HARD WIRING PRIOR TO INSTALLATION

9

12

11

11

10

4

5

6

7

7

8

8

4a

4c

4

4b

REMOVE THE LOWER DRAWER

TERMINATE THE WIRING AS SHOWN

REMOVE THE ACCESS COVER & POWER CORD

100 mm

2

4

5

1

4” (100mm)

To prevent kinked hoses, we recommend

rotating the drawer anti-clockwise and

resting it on its side after removal.

Access

cover

Press the release tabs in on

either side and push back

to release drawer from

runners.

3

Remove knock-out for cable clamp and
fit a suitable cable clamp for the conduit.

Use copper conductors only.

4d

REFIT THE DRAWER ONTO THE RUNNERS & CLOSE

13

14

15

16

19

Before refitting the drawer,

ensure the hoses are not

twisted and the latches at

the rear of each drawer

runner are facing forward.

Ensure the release tabs on

both sides are reset fully.

Ensure the drawer

is now rotated

clockwise back.

Pull fo

rward the r

elease tabs

on both sides 4”(100

mm)

Electrical Shock Hazard

Before continuing, ensure that the product is
disconnected from the power supply.

Failure to follow this warning may result in
electrical shock, injury or fire.

WARNING!
