FujiFilm F480/F485 - Manual (Page 121)

121
Continued Q
Battery NP-40N
Nominal voltage DC 3.6V
Nominal capacity 760 mAh
Operating temperature 0°C to +40°C (+32°F to +104°F)
Dimensions 35.3 mm × 40.0 mm × 5.85 mm(1.4
in. × 1.6 in. × 0.2 in.)(W × H × D)
Mass (Weight) Approx. 18 g (0.6 oz.)
Battery Charger BC-40N
Rated input 110-240 V AC, 50/60 Hz
Input capacity 7 VA
Rated output 4.2 V DC, 550 mA
Applicable batteries Rechargeable Battery NP-40N
Charging time Approx. 120 minutes
Dimensions 88.0 mm × 54.0 mm × 20.0 mm (3.5
in. × 2.1 in. × 0.7 in.) (L × W × D)
Mass (Weight) Approx. 58 g (2.0 oz.) (excluding
batteries)
Operating
temperatures
0°C to + 40°C(+ 32°F to + 104°F)
Notes on Using the Battery Charger
Use with the following power supply cord set:
Cord: UL Listed, Type SPT-2, No.18 AWG, rated 300V,
10A, minimum 4 ft (1.2m), maximum 10 ft (3m) long.
One end terminates in a molded-on, parallel-blade, (non-
polarized) attachment plug with a 7A, 125V (NEMA 1-
15P) configuration.
• The battery and battery charger themselves will
become warm due to the power stored inside them. This
is normal and does not indicate a fault. Wherever
possible, use the battery charger in a well-ventilated
location.
• There may be vibration noises from inside the battery
charger during use. This is normal and does not indicate
a fault.
• Do not use the battery charger to charge batteries other
than rechargeable battery NP-40N.
• The battery charger could cause interference if placed
close to a radio during charging. In this event, move the
radio and charger further apart.
• Do not leave the battery charger in the following types
of locations:
• Extremely humidity or high temperatures, such as close
to a heating appliance or in direct sunlight
• Places with strong vibration
• In very dusty places
• The battery charger accepts input voltages of 110-240
V AC at 50 or 60 Hz and can be used all over the world.
However, the shape of the plug and socket-outlet
depends on the country of use. Consult your travel
agent for details.
