AP-1
APPENDIX 1
TRANSDUCER 50BL-12/50BL-24H
When using the transducer 50BL-12/50BL-24H, see this appendix.
Transducer, thru-hull pipe and tank list
Frequency
(kHz)
Transducer
Hull
Material
Tank
(Code No.)
Fasten inside
hull (Code No.)
Fasten outside
hull (Code No.)
Steel
T-693
(000-015-044)
TWB-6000
(000-015-207)
TFB-7000
(000-015-209)
50/200 50BL-12/200B-8B
FRP
T-693F
(000-015-241)
TWB-1100
(000-015-218)
-
Steel
T-696
(000-015-048)
TWB-6000
(000-015-207)
TFB-7000
(000-015-209)
28/50 28F-24H/50BL-24H
FRP
T-696F
(000-015-244)
TRB-1100
(000-015-218)
-
Steel
T-697
(000-015-239)
TWB-6000
(000-015-207)
TFB-7000
(000-015-209)
50/88 50BL-24H/88F-126H
FRP
T-697F
(000-015-245)
TRB-1100
(000-015-218)
-
Steel
T-695
(000-015-047)
TWB-6000
(000-015-207)
TFB-7000
(000-015-209)
50/200 50BL-24H/200B-12H
FRP
T-695F
(000-015-243)
TRB-1100
(000-015-218)
-
Settings
1. Referring page 3-6, set the menu as below.
XDCR SELECT: MANUAL
FREQ: 50 kHz
2. At the terminal board at the rear of the display unit, fasten the crimp-on lug to C position.
(See page 3-5.)
Frequency Output (kW) Transducer Terminal
2 50BL-12 C
50
3 50BL-24H C
