3. INITIAL SETTINGS
3-10
Adjustment value =
Actual value - Indication of FCV-1100L
Actual value
x 100 (%)
c) Press [!] or ["] to close the dialog box.
10. Press ["] to select SPEED OUTPUT, and then press the [+] or [-] key to open the dialog
box.
11. Use [+] or [-] to turn the speed output ON (default setting) or OFF, and press [!] or ["]
to close the dialog box.
12. Press ["] to select SPEED INFO, and then press [+] or [-] to open the dialog box.
OFF ON
13. Press [+] or [-] to turn the speed indication (NMEA) OFF (default setting) or ON, and
then press [!] or ["] to close the dialog box. If no navigator is connected, turn the
[FUNCTION] switch to other position to quit.
14. Press ["] to select NMEA VERSION, and then press [+] or [-] to open the dialog box.
Ver 1.5 Ver 2.0 Ver 3.0 SPECIAL
15. Use [+] or [-] to select NMEA version no. (default setting is Ver 2.0) of the navigator, and
then press [!] or ["] to close the dialog box. If you are unsure of the version no., try all
three to see which one successfully receives position data. SPECIAL is for use with a
navigator whose baud rate is 600 bps.
16. Press ["] to select NAV DATA, and then press [+] or [-] to open the dialog box.
LC LA DECCA GPS DR AUTO
17. Use [+] to select type of navigator connected, and then press [!] or ["] to close the
dialog box. AUTO (default setting) selects a navigator in the order of GPS, Loran C,
Loran A, Decca, DR (Dead Reckoning).
18. Press ["] to select COURSE, and then press [+] or [-] to open the dialog box.
TRUE MAG
19. Use [+] or [-] to select TRUE or MAG (magnetic bearing) as appropriate, and then press
[!] or ["] to close the dialog box. TRUE is the default setting.
20. Press["] to select TLL (Target latitude, Longitude) OUTPUT, and then press [+] or [-] to
open the dialog box.
OFF ON
21. TLL OUTPUT enables or disables output of position data from the video sounder to
external equipment, at the moment the [MARKER TLL] key is pressed. Use [+] or [-] to
select ON or OFF (default setting) as appropriate, and then press [!] or ["] to close the
dialog box.
22. Turn the [FUNCTION] switch to EXIT position to quit.
OFF ON
