3. INITIAL SETTINGS
3-8
6. Press ["] to select TEMP INPUT, and then press [+] or [-] to open the dialog box.
SENSOR NMEA
7. Use [+] or [-] to select source of water temperature data, and then press [!] or ["] to
close the dialog box.
SENSOR: Water temperature sensor T-02MSB, T-02MTB or T-03MSB inputs water
temperature data. This is the default setting.
NMEA: Water temperature data input from external equipment.
8. When selecting SENSOR at TEMP INPUT, you may offset water temperature data to
further refine its accuracy. This must be done with the boat in water.
a) Press ["] to select TEMP ADJUT, and then press [+] or [-] to open the dialog box.
+0.00
b) Watch the water temperature readout on the monitor (if it is not displayed set TEMP
READOUT to ON) and compare it with known value.
c) Use [+] or [-] to enter the difference found in b) above. For example, if the indication of
the FCV-1100L is +5
°
higher than the actual value, enter –5 (degree).
d) Press [!] or ["] to close the dialog box.
9. Press ["] to select TEMP OUTPUT, and then press [+] or [-] to open the dialog box.
OFF ON
10. Use [-] or [+] to turn the water temperature indication (NMEA) ON or OFF respectively,
and then press [!] or ["] to close the dialog box.
11. Press ["] to select TEMP READOUT, and then press [+] to open the dialog box.
OFF ON
12. Use [-] or [+] to select the temperature display, and press [!] or ["] to close the dialog
box.
13. Press ["] to select TEMP GRAPH and [+] or [-] to open the dialog box.
OFF NARROW STD EXPAND
14. Press [+] or [-] to select temperature scale graduation interval, and then press [!] or ["]
to close the dialog box.
15. Press ["] to select TEMP COLOR and [+] or [-] to open the dialog box.
STD WHITE RED BLACK YELLOW
16. Use [+] or [-] to select the color of the water temperature graph for STD (blue in default
setting but then press [!] or ["] to close the dialog box.
17. Turn the [FUNCTION] switch to EXIT position to quit.
