8 T6137pr-0920
Assembly
Motor Harness
Connector Wire
Children can be harmed by small
parts, sharp edges and sharp points
in the vehicle’s unassembled state,
or by electrical items. Care should be
taken in unpacking and assembly of
the vehicle. Children should not handle
parts, including the battery, or help in
assembly of the vehicle.
WARNING
FRONT VIEW
1
Dash
Key Assembly
Position the dash on the vehicle. •
Make sure the motor harness connector wire is •
through the groove in the dash. Insert five #10 x ¾"
screws and tighten.
2
17
18
Before applying labels, wipe the surface of the vehicle •
with a clean, dry cloth to remove any dust or oils.
Place the labels exactly as shown in the illustration.
•
For best results, avoid repositioning a label once it has •
been applied to the vehicle.
DASH VIEW
2
3
Insert and • “snap” the key assembly into the opening
in the dash, as shown.
#10 x 3 /
4
" Screws
Dash
